Straight Bevel Gears
When a bevel gear runs in heavy industrial equipment, it has to carry load and hold its pattern run after run. We cut straight bevel gears up to 18" OD and 3" face width, in fine and coarse pitches, with ratios from 1:1 to 1:10 and a coniflex or conventional bearing pattern.
Every gear is built to print for new applications, or reverse-engineered from a worn sample when the original is obsolete. We machine them in annealed, hardened, and stainless steel, along with other ferrous and nonferrous materials.
Every gear is built to print for new applications, or reverse-engineered from a worn sample when the original is obsolete. We machine them in annealed, hardened, and stainless steel, along with other ferrous and nonferrous materials.
Specifications
MAX PART diameter
18” OD
MAX FACE WIDTH
3"
Pitch Range
3 - 16 DP
Pressure Angle
14.5 - 25°
Custom Straight Bevel Gear Samples
teeth
37
DIAMETRAL PITCH
12 DP
PRESSURE ANGLE
14.5°
PITCH DIAMETER
3.083"
teeth
14
DIAMETRAL PITCH
5 DP
PRESSURE ANGLE
20°
PITCH DIAMETER
2.800"
teeth
52
DIAMETRAL PITCH
6 DP
PRESSURE ANGLE
20°
PITCH DIAMETER
8.666"
Gear quality is our top priority.
From prototypes to AGMA 15 gears, each part is verified with in-house inspection.
